Post Forge Operations

By providing heat treatment services in-house, NKH is able to maintain greater control over heat treating process. The facility comprise batch furnaces both oil fired & electrical, continuous electrical heating furnaces, solution treatment etc. to carry out annealing, Normalising, hardening, tempering, iso-thermal annealing, solution treatment etc. or other operations as specified by our customer. Close temperature control and process monitoring with the help of temperature recorders ensures uniform properties duly supported by evaluation of metallurgical properties through representative test piecesand test accordingly mentioned below on the available facilities provided by our Facilitation center, which is NATIONAL ACCREDITION BOARD FOR TESTING AND CALIBRATION LAB (NABL) APPROVED.

Vacuum Heat Treatment of Tools And Dies Steel

• Vacuum heat treatment furnace chamber size 600 x 600 x 900 mm

Continuous Furnace

MESH BELT SIZE(WIDTH)

400 mm (MAX.)

FURNACE INLET OPENING HEIGHT

80 mm (MAX.)

HARDNING ZONE

LENGTH

5500 mm

TEMPRATURE RANGE

850oC – 925oC

TEMERING ZONE

LENGTH

6000 mm

TEMPRATURE RANGE

200oC – 700oC

QUENCHING MEDIUM

FAST QUENCH OIL

TYPE OF PROTECTIVE ATMOSPHERE

METHANOL & LPG.

Cp ( %AGE CARBON)

0.2 TO 0.6

AUTO MATICMANUAL

SIZE mm WEIGHT gms.

MATERIAL LOADING

150×80 400 ( max.)

SIZE mm WEIGHT gms.

300×80 800 ( max.)

WASHERS

PRE WASHER BEFORE HARDING

POST WASHER AFTER OIL QUENCHING

PRODUCTION CAPACITY

300 Kg/HRS

7-TONS/DAY

forging of a tailpin general forging shot shafts cooling after heat treatment
upset forged shafts shotblasted upset forging furnaces and shaft forging
crankshaft forging flight bar forging forging pistons
furnaces heating billets for flight bar forging axle forging
Induction Hardening

• Medium Frequency Induction Hardening Machine 90 Kw, 3 – 10 KHz InductoThermmake.

Gas Carburising

• Gas Carburising Furnace. Ø600 x 1100

• Gas Nitriding Furnace. Ø600 x 1200

Capacity: Ø600 x 1200mm, simplicity.

• Tempering Furnace

Capacity: Ø600 x 1100mm, Simplicity.

Tufftriding

• Liquid Nitriding / Tuff Triding Furnace of Western Engineers make

Cryogenics Processing

• Cryogenics Processor with Tempering Facility (-110°C to -196°C) PrimeroEnServemake. Size 400 x 1200 x 400.

Shot blasting, Grinding are all conducted in house along with Magnetic Particle Inspection.
